Genlab Multi Purpose Benchtop Ovens
The Genlab range of Benchtop Ovens offers a range of highly efficient, reliable and cost effective ovens to suit most warming, drying and heat treatment processes. Available in a variety of sizes and designed with both side or base mounted displays to suit your exact needs. Featuring our latest touch screen control system which offers intuitive control and excellent accuracies designed for industrial and laboratory ovens. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Specifications
|
Options
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Benchtop Oven Specifications
|
Benchtop Oven Design
The exterior is constructed from sheet steel and finished in an easy clean powder coated paint. The interior chamber is made from mild steel coated with aluminium (CLAD), with a stainless steel (SS) chamber available as an option.They are fitted with fixed shelf runners and removable chrome plated wire grid shelves.
Benchtop Oven Heating
Heated by Incoloy sheathed elements; positioned in the base of the oven on all natural convection ranges. Fan assisted ranges have elements in the rear on base mount designs and in the side on side mount designs.
The 200 litre units have fan circulation as standard.
Benchtop Oven Controls
The control system comprises of a bespoke touch screen interface that offers both accurate temperature control and an integral overheat system using 2 individual Pt100 sensors. Advanced features can be turned on and off to suit bespoke heating applications and tailored to customer preference. Oven trending is displayed for up to 48 hours and optional upgrades are available for alarm outputs
Ordering
All units have CLAD interior with a touch screen interface as standard.
Where options are required simply add the option code to the original reference.
E.g. MINO/50/TDIG with fan assisted convection and stainless steel interior and fan circulation becomes MINO/50/TDIG/SS/F
Contact sales for bespoke options
Option codes
Fan Assisted Circulation – F
Stainless Steel Chamber – SS
3 Stage Advanced Timer – TIM
Access ports – AP
Audible Warning – AWA
Single Points Calibrations – SPC
Temp Uniformity Surveys – TUS
Extraction Systems – EXT
Extended Warranty – X1
Explosion Relief Panels (OV style only) – EXP
